Befaco Bandit
$155.00 - $200.00
A spectral processing playground
Bandit is a fun combination of band-pass filters, VCAs, and routing options.
It serves multiple functions including equalizer, crossover, multiband VCA, 4 band spectral mixer, and spectral external FX insert point.
Bandit allows you to...
- Cut or emphasize different frequency bands of a signal, acting as a voltage-controlled equalizer/isolator.
- Split a sound into four different frequency bands for external processing, and if needed, insert them back
- Mix four different signals with predefined tone placement in the mix.
- Create four different sounds from one sound source by modulating the volume with four different envelopes.
- Create evolving timbres by modulating one or more frequency bands using LFOs or audio-rate modulation.
FEATURES
- Four Band CV controllable EQ
- Individual inputs per Band
- Return inputs
- Level and Peak LEDs
SPECS
- Current needs: +12V: 80mA, -12: 70mA, 5v:0
- Width: 8 HP
- Depth: 30mm (including power connector)
- Designed, kits prepared and modules assembled in Barcelona
