DIY Kits

This is a raw 12HP 1U version of the Mobius PiLL. It uses two cross-coupled Phase locked loop (PLL) ICs that go in and out of chaotic zones at audio rates. If you like making electronic noise, this module is for you. Oh yeh, it has vactrols.It is a...

  Nonlinear Circuits Cellular Automata 12hp This is a 16 cell gate and pattern generator using cellular automata rules 90 & 150. It will run thru a process driven by a clock signal and requires a signal on one of the seed inputs (anything...

  The NLC Dispersion Delay is three vactrol based bandpass filters in parallel, with each filter feeding into a voltage controlled delay stage. The outputs are available individually or there is an OUT ALL mode where all 3 signals are mixed. ...

This module is a dual sample & hold with voltage controlled slew for each channel. It contains a simple jerk chaos circuit running at approx. 300Hz to supply a signal for sampling. So, it is similar to the Buchla 265 Source of Uncertainty except is...

An 6hp reinvention of the Mutable Instruments - Warps module. Developed by Jim with Neutron Sound this is another micro variation of a staple in the Mutable Instruments line.

These are Sloth chaos modules available in 1U 6HP panels. The panels are available in Pulp and Intellijel formats, please specify when ordering. Please note, the PCBs only have eurorack 10 pin power connectors, not the Pulp Logic 3 pin type. They are...

This is another somewhat lazy design, but a nice easy build.. Basically grabbed the NLC Triad and replaced the pots for Attack & Decay with vactrols Not sure why it hasn’t been done before, it is a simple circuit and the results are fun; lots...
